Part No 104Q
Manufacturer Hammond Manufacturing
Catalog Audio Transformers
Description AUDIO XFMR 500CT / 3.2 TH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Impedance - Primary (Ohms) 500CT
Impedance - Secondary (Ohms) 3.2
DC Resistance (DCR) - Primary 27Ohm
DC Resistance (DCR) - Secondary 400mOhm
Transformer Type Miniature Epoxy Potted
Frequency Range 200Hz
Frequency Response -1dB
Voltage - Isolation 200V
Insertion Loss 1dB
Power Level 500mW
Mounting Type Through Hole
Size / Dimension 0.860" L x 0.710" W (21.84mm x 18.03mm)
Height - Seated (Max) 0.750" (19.05mm)
Termination Style PC Pin
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1510548-104Q
Ultra Librarian 3D Model Ultra Librarian 104Q CAD Model
