M52-040000P0545 Real Image
Same model may have multiple batches, images only for reference.

M52-040000P0545

Part No M52-040000P0545
Manufacturer Harwin Inc.
Catalog Rectangular Connectors
Description CONN HEADER SMD 5POS 1.27MM / Connector Header Surface Mount 5 position 0.050" (1.27mm)
Datasheet
M52-040000P0545 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects - Rectangular Connectors - Headers, Male Pins
Mfr Harwin Inc.
Series Archer M52
Package Bulk
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.050" (1.27mm)
Number of Positions 5
Number of Rows 1
Number of Positions Loaded All
Style Board to Board
Shrouding Unshrouded
Mounting Type Surface Mount
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.157" (4.00mm)
Insulation Height 0.098" (2.50mm)
Contact Shape Square
Contact Finish - Mating Gold
Contact Finish Thickness - Mating Flash
Contact Material Brass
Insulation Material Polyamide (PA6T) , Nylon 6T
Temperature Range - Operating -40°C ~ 105°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Current Rating (Amps) 1A
Mated Stacking Heights 8.37mm, 9.77mm, 12.27mm
Base Product Number M52-040
Standard Package 500
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
Win Source Part Number 1339095-M52-040000P0545
Ultra Librarian 3D Model Ultra Librarian M52-040000P0545 CAD Model

Description

The 1339095-M52-040000P0545 is a male pin header type connector from Harwin Inc.

  • Series: Archer M52
  • Positions: 5
  • Row Count: single row
  • Pitch: 0.050" (1.27mm)
  • Packaging: bulk
  • Mounting: surface mount
  • Material: brass
  • Contact Finish: gold
  • Finish Thickness: flash
  • MSL Level: 1 (unlimited)
  • HTSUS: 8536.69.4040
  • REACH: unaffected
  • Current Rating: 1A
