Same model may have multiple batches, images only for reference.

M20-7831146

Name: M20-7831146
Brand: Harwin Inc.
SKU: 805160
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	M20-7831146
Manufacturer	Harwin Inc.
Catalog	Rectangular Connectors
Description	CONN RCPT 22POS 0.1 TIN PCB
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Manufacturer	Harwin Inc.
Packaging	Tube
Part Status	Obsolete (End Of Life)
Connector Type	Receptacle
Contact Type	Female Socket
Style	Board to Board or Cable
Number of Positions	22
Number of Positions Loaded	All
Pitch - Mating	0.100" (2.54mm)
Number of Rows	2
Row Spacing - Mating	0.100" (2.54mm)
Mounting Style	Through Hole
Termination	Solder
Fastening Type	Push-Pull
Contact Finish - Mating	Tin
Insulation Color	Black
Insulation Height	0.335" (8.51mm)
Contact Length - Post	0.118" (3.00mm)
Temperature Range - Operating	-40°C ~ 105°C
Material Flammability Rating	UL94 V-0
Contact Finish - Post	Tin
Mated Stacking Heights	11.04mm, 12.63mm
Current Rating (Amps)	3A
Voltage Rating	1000V
Applications	General Purpose, Industrial, Telecommunications
Insulation Material	Polyamide (PA6T), Nylon 6T
Contact Shape	Square
Contact Material	Phosphor Bronze
Manufacturer Pack Quantity	20
MSL Level	1 (Unlimited)
Popularity	Medium
Supply and Demand Status	Balance
Win Source Part Number	805160-M20-7831146
Ultra Librarian 3D Model	Ultra Librarian M20-7831146 CAD Model

Alternative Products

Description

The Harwin Inc. 805160-M20-7831146 is a through-hole receptacle connector with a push-pull fastening type.

Positions: 22
Rows: 2
Applications: Board-to-board or cable connections
Voltage Rating: 1000V
Current Rating: 3A
Insulation Material: Polyamide (PA6T) and nylon 6T
Contact Material: Phosphor bronze
Contact Type: Female socket
Contact Finish: Tin
Pitch-Mating: 0.100" (2.54mm)
Insulation Color: Black
Row Spacing-Mating: 0.100" (2.54mm)
Contact Length-Post: 0.118" (3.00mm)
Insulation Height: 0.335" (8.51mm)
Applications: General purpose, industrial, and telecommunications
Status: Obsolete (End Of Life)
Packaging: Tube
Manufacturer Pack Quantity: 20
