The 2SCR553P5T100 is a PNP silicon epitaxial transistor manufactured by Rohm Semiconductor. It is designed for switching and amplification applications where low saturation voltage and high current gain are crucial.

Applications

• Switching circuits in various electronic devices.
• Amplification stages in audio and signal processing circuits.
• DC-DC converters.
• Load switches in power management systems.
• Motor control circuits.

Features

• Low collector-emitter saturation voltage (VCE(sat)): Minimizes power loss during switching.
• High DC current gain (hFE): Ensures efficient amplification.
• Fast switching speed: Suitable for high-frequency switching applications.
• Surface-mount package: Allows for compact circuit designs.
• Lead-free construction: Compliant with environmental regulations.

Benefits

• Improved energy efficiency due to low saturation voltage.
• Enhanced amplification performance with high current gain.
• Suitable for high-speed switching applications.
• Compact designs due to surface-mount packaging.
• Environmentally friendly due to lead-free construction.

Additional Details

The 2SCR553P5T100 is typically packaged in a SOT-23 package. Key electrical characteristics include a collector-emitter voltage (VCEO) of -50V, a collector current (IC) of -500mA, and a power dissipation (PC) of 200mW. It boasts a typical hFE of 100 to 320, ensuring good amplification characteristics. Its fast switching speed and low saturation voltage make it a valuable component in various electronic applications.
