The PEEL18CV8T-7 is a Programmable Electrically Erasable Logic (PEEL) device manufactured by ICT. These devices are used for implementing custom logic functions, acting as a flexible alternative to discrete logic gates. The T-7 indicates a speed grade, meaning a propagation delay of 7ns.

Applications

• Address decoding in memory systems
• State machine implementation
• Peripheral controllers
• Glue logic for interfacing different components
• Timing control circuits

Features

• Electrically erasable and reprogrammable
• Low power consumption
• High speed operation (7ns propagation delay)
• Eight output macrocells
• TTL compatible inputs and outputs
• Flexible output configuration

Benefits

• Simplifies circuit design by replacing multiple discrete logic gates
• Reduces board space and component count
• Allows for easy design changes and updates
• Provides a cost-effective solution for custom logic implementation
• Improves system performance due to high speed operation

Additional Details

The PEEL18CV8T-7 typically operates on a 5V power supply. It features a programmable AND array and a fixed OR array. Each output macrocell can be configured as either a combinational output, a registered output, or an input. The device is programmed using a standard PEEL programmer. Its electrically erasable nature allows for in-system reprogramming. This feature is particularly beneficial in prototyping and debugging new designs where frequent logic changes are required.

This PEEL device provides a versatile solution for a wide range of digital logic applications, offering a balance of flexibility, performance, and cost-effectiveness. Its reprogrammability allows for design iterations without the need for physical hardware changes, saving time and resources during development. The fast propagation delay ensures high-speed operation, making it suitable for performance-critical applications.
