2EDF7275KXUMA1

Name: 2EDF7275KXUMA1
Brand: Infineon Technologies
SKU: 1372492
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	2EDF7275KXUMA1
Manufacturer	Infineon Technologies
Catalog	PMIC - Gate Drivers
Description	IC GATE DRVR HALF-BRIDG TFLGA-13 / Half-Bridge Gate Driver IC Non-Inverting PG-TFLGA-13-1
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Integrated Circuits (ICs) - Power Management (PMIC) - Gate Drivers
Mfr	Infineon Technologies
Series	EiceDriver™
Package	Tape & Reel
Driven Configuration	Half-Bridge
Channel Type	Independent
Number of Drivers	2
Gate Type	N-Channel, P-Channel MOSFET
Voltage - Supply	20V
Logic Voltage - VIL, VIH	-, 1.65V
Current - Peak Output (Source, Sink)	4A, 8A
Input Type	Non-Inverting
Rise / Fall Time (Typ)	6.5ns, 4.5ns
Temperature Range - Operating	-40°C ~ 125°C (TA)
Mounting Type	Surface Mount
Package / Case	13-TFLGA
Supplier Device Package	PG-TFLGA-13-1
Base Product Number	2EDF7275
MSL Level	3 (168 Hours)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8542.39.0001
Win Source Part Number	1372492-2EDF7275KXUMA1
Ultra Librarian 3D Model	Ultra Librarian 2EDF7275KXUMA1 CAD Model

Alternative Products

Description

The 2EDF7275KXUMA1 is a gate driver IC from Infineon Technologies.

Series: EiceDriver
Temperature Range: -40°C to 125°C
Voltage - Supply: 20V
Package / Case: 13-TFLGA
Mounting Type: Surface Mount
Rise / Fall Time (Typ): 6.5ns, 4.5ns
Configuration: High-Side and Low-Side
Channel Type: Independent
Gate Type: N-Channel, P-Channel MOSFET
Input: Non-Inverting
REACH Status: Unaffected
ECCN: EAR99
