BSC011N03LS Infineon Technologies BSC011N03LS Real Image
Same model may have multiple batches, images only for reference.
BSC011N03LS Infineon Technologies BSC011N03LS Real Image
BSC011N03LS Infineon Technologies BSC011N03LS Real Image
Same model may have multiple batches, images only for reference.

BSC011N03LS

Part No BSC011N03LS
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 30V 100A 8TDSON
Datasheet
BSC011N03LS Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 37A (Ta), 100A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2.2V @ 250μA
Max Gate Charge 72nC @ 10V
Max Input Capacitance 4700pF @ 15V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 2.5W (Ta), 96W (Tc)
Maximum Rds On at Id,Vgs 1.1 mOhm @ 30A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package PG-TDSON-8
Dimension 8-PowerTDFN
Win Source Part Number 039679-BSC011N03LS
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian BSC011N03LS CAD Model

Description

BSC011N03LS N-Channel MOSFET

The BSC011N03LS is a high-performance N-channel power MOSFET, designed for optimum efficiency and reliability in various electronic circuits. Its compact footprint and exceptional thermal characteristics make it ideal for demanding applications.

  • Applications:
    • Switching converters
    • Motor control systems
    • Battery management systems
  • Features & Benefits:
    • Low on-resistance for minimal power loss
    • High-speed switching capability
    • Robust design with high current handling capacity
  • Additional Details:
    • Optimized for efficient performance in both linear and switching modes
    • Reliability ensured through rigorous testing processes
