BSG0811NDATMA1

Name: BSG0811NDATMA1
Brand: Infineon Technologies
SKU: 970745
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	BSG0811NDATMA1
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET 2N-CH 25V 19A/41A 8TISON / Mosfet Array 2 N-Channel (Dual) Asymmetrical 25V 19A, 41A 2.5W Surface Mount PG-TISON-8
Datasheet	BSG0811NDATMA1 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products>Transistors - FETs, MOSFETs - Arrays
Mfr	Infineon Technologies
Series	OptiMOS™
Package	Tape & Reel
FET Type	2 N-Channel (Dual) Asymmetrical
FET Feature	Logic Level Gate, 4.5V Drive
Drain to Source Voltage (Vdss)	25V
Current - Continuous Drain (Id) @ 25°C	19A, 41A
Rds On (Max) @ Id, Vgs	3mOhm @ 20A, 10V
Vgs(th) (Max) @ Id	2V @ 250µA
Gate Charge (Qg) (Max) @ Vgs	8.4nC @ 4.5V
Input Capacitance (Ciss) (Max) @ Vds	1100pF @ 12V
Power - Max	2.5W
Temperature Range - Operating	-55°C ~ 150°C (TJ)
Mounting	SMD (SMT)
Package / Case	8-PowerTDFN
Supplier Device Package	PG-TISON-8
Base Product Number	BSG0811
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.29.0095
Other Names	BSG0811NDATMA1-ND,BSG0811NDATMA1TR,SP001075902,BSG0811NDATMA1CT,BSG0811NDATMA1DKR
Standard Package	5,000
Win Source Part Number	970745-BSG0811NDATMA1
Ultra Librarian 3D Model	Ultra Librarian BSG0811NDATMA1 CAD Model

Alternative Products

Description

The BSG0811NDATMA1 is a dual N-Channel MOSFET transistor from the OptiMOS™ series of Infineon Technologies.

Drain to Source Voltage (Vdss): 25V
Continuous Drain Current (Id): 19A and 41A @ 25°C
Rds On (Max) @ Id, Vgs: 3mOhm @ 20A, 10V
Gate Charge (Qg) (Max) @ Vgs: 8.4nC @ 4.5V
Package: 8-PowerTDFN
Mounting Type: Surface Mount Technology (SMT)
Application: power supplies, motor control, and DC-DC converters
