BSP316PH6327XTSA1 Real Image BSP316PH6327XTSA1 Real Image
Same model may have multiple batches, images only for reference.
BSP316PH6327XTSA1 Real Image BSP316PH6327XTSA1 Real Image
BSP316PH6327XTSA1 Real Image BSP316PH6327XTSA1 Real Image
Same model may have multiple batches, images only for reference.

BSP316PH6327XTSA1

Part No BSP316PH6327XTSA1
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 100V 0.68A SOT223
Datasheet
BSP316PH6327XTSA1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 100V
Continuous Drain Current at 25°C 680mA (Ta)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2V @ 170μA
Max Gate Charge 6.4nC @ 10V
Max Input Capacitance 146pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 1.8W (Ta)
Maximum Rds On at Id,Vgs 1.8 Ohm @ 680mA, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package PG-SOT223-4
Dimension TO-261-4, TO-261AA
Win Source Part Number 118736-BSP316PH6327XTSA1
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian BSP316PH6327XTSA1 CAD Model

Description

Product Description

The BSP316PH6327XTSA1 is a premium N-channel MOSFET that offers robust functionality in power management and control systems. Known for its low power consumption and high-speed operation, it is a crucial component for advanced electronics.

Applications and Projects

  • Embedded systems
  • Telecommunications equipment
  • Renewable energy systems
  • Control modules

Features and Benefits

  • Excellent switching characteristics
  • Minimal energy loss
  • Long-lasting durability
  • Compact and lightweight design

The BSP316PH6327XTSA1 is engineered to enhance energy efficiency and longevity in high-demand applications. Its precision engineering provides unmatched performance in both consumer and industrial applications.
