IKW75N65EH5XKSA1 Infineon Technologies
Same model may have multiple batches, images only for reference.

IKW75N65EH5XKSA1

Part No IKW75N65EH5XKSA1
Manufacturer Infineon Technologies
Catalog IGBTs - Single
Description IGBT TRENCH 650V 90A TO247-3 / IGBT Trench 650 V 90 A 395 W Through Hole PG-TO247-3
Datasheet
IKW75N65EH5XKSA1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products>Transistors - IGBTs - Single
Mfr Infineon Technologies
Series TrenchStop™
Package Tube
IGBT Type Trench
Voltage - Collector Emitter Breakdown (Max) 650 V
Current - Collector (Ic) (Max) 90 A
Current - Collector Pulsed (Icm) 300 A
Vce(on) (Max) @ Vge, Ic 2.1V @ 15V, 75A
Power - Max 395 W
Switching Energy 2.3mJ (on), 900µJ (off)
Input Type Standard
Gate Charge 160 nC
Td (on/off) @ 25°C 28ns/174ns
Test Condition 400V, 75A, 8Ohm, 15V
Reverse Recovery Time (trr) 92 ns
Temperature Range - Operating -40°C ~ 175°C (TJ)
Mounting Type Through Hole
Package / Case TO-247-3
Supplier Device Package PG-TO247-3
Base Product Number IKW75N65
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.29.0095
Other Names SP001257948
Standard Package 30
Win Source Part Number 1176208-IKW75N65EH5XKSA1
Ultra Librarian 3D Model Ultra Librarian IKW75N65EH5XKSA1 CAD Model

Description

The 1176208-IKW75N65EH5XKSA1 is a discrete semiconductor product designed for use in transistors, specifically IGBTs. It is a member of the TrenchStop series and features a TO-247-3 package.

  • GPTDescription: The product can handle a maximum power of 395 W and has a reverse recovery time of 92 ns.
  • GPTDescription: The IGBT type is trench, and the voltage for collector emitter breakdown is 650 V.
  • GPTDescription: The product can handle a maximum collector current of 90 A and a maximum collector pulsed current of 300 A.
  • GPTDescription: The switching energy for the product is 2.3mJ (on) and 900µJ (off).
  • GPTDescription: The input type is standard, and the gate charge is 160 nC.
  • GPTDescription: The product has a Td (on/off) @ 25°C of 28ns/174ns and operates within a temperature range of -40°C to 175°C (TJ).
  • GPTDescription: The 1176208-IKW75N65EH5XKSA1 is an excellent choice for developers who require a reliable transistor for their projects.
