IR2104STRPBF Real Image IR2104STRPBF real image221 IR2104STRPBF Real Image
Same model may have multiple batches, images only for reference.
IR2104STRPBF Real Image IR2104STRPBF real image221 IR2104STRPBF Real Image
IR2104STRPBF Real Image IR2104STRPBF real image221 IR2104STRPBF Real Image
Same model may have multiple batches, images only for reference.

IR2104STRPBF

Part No IR2104STRPBF
Manufacturer Infineon Technologies
Catalog PMIC - Gate Drivers
Description IC DRIVER HIGH/LOW SIDE 8SOIC
Datasheet
IR2104STRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits(ICs)
Family PMIC - Gate Drivers
Manufacturer Infineon Technologies
Packaging Reel(TR)
Driven Configuration Half-Bridge
Channel Type Synchronous
Number of Drivers 2
Gate Type IGBT, N-Channel MOSFET
Operating Supply Voltage 10 V ~ 20 V
Logic Voltage - VIL, VIH 0.8V, 3V
Current - Peak Output (Source, Sink) 210mA, 360mA
Input Type Non-Inverting
High Side Voltage - Max (Bootstrap) 600V
Rise / Fall Time (Typ) 100ns, 50ns
Operating Temperature Range -40°C ~ 150°C (TJ)
Mounting Style SMD/SMT
Package 8-SOIC (0.154", 3.90mm Width)
Manufacturer Device Package 8-SOIC
Win Source Part Number 017346-IR2104STRPBF
Family Name IR2104
Introduction Date May 02, 2001
ECCN EAR99
Country of Origin Thailand
Halogen Free Not Compliant
Estimated EOL Date 2022
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian IR2104STRPBF CAD Model

Description

The Infineon Technologies IR2104STRPBF is a PMIC - gate driver designed for use in integrated circuits.

  • Mounting: SMD/SMT
  • Package: 8-SOIC
  • Operating Temperature: -40°C to 150°C
  • Operating Supply Voltage: 10V to 20V
  • Channel Type: synchronous
  • Input Type: non-inverting
  • Driven Configuration: half-bridge
  • Gate Type: IGBT, N-Channel MOSFET
  • Number of Drivers: 2
