IR2113STRPBF Real Image IR2113STRPBF real image226
Same model may have multiple batches, images only for reference.
IR2113STRPBF Real Image IR2113STRPBF real image226
IR2113STRPBF Real Image IR2113STRPBF real image226
Same model may have multiple batches, images only for reference.

IR2113STRPBF

Part No IR2113STRPBF
Manufacturer Infineon Technologies
Catalog PMIC - Gate Drivers
Description IC MOSFET DRVR HI/LO SIDE 16SOIC
Datasheet
IR2113STRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Driven Configuration Half-Bridge
Channel Type Independent
Number of Drivers 2
Gate Type IGBT, N-Channel MOSFET
Supply Voltage - Operating 3.3 V to 20 V
Logic Voltage - VIL, VIH 6V, 9.5V
Current - Peak Output (Source, Sink) 2A, 2A
Input Type Non-Inverting
High Side Voltage - Max (Bootstrap) 600V
Rise and Fall Time 25ns, 17ns
Temperature Range - Operating -40°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 16-SOIC
Win Source Part Number 017360-IR2113STRPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name IR2113
Introduction Date March 26, 2004
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian IR2113STRPBF CAD Model

Description

The Infineon Technologies IR2113STRPBF is an independent channel type half-bridge driver IC that is used in motor drive and control applications.

  • Channel Type: Independent
  • Input Type: Non-Inverting
  • Driven Configuration: Half-Bridge
  • Gate Type: IGBT and N-Channel MOSFET
  • Logic Voltage (VIL): 6V
  • Logic Voltage (VIH): 9.5V
  • Peak Output Current (Source): 2A
  • Peak Output Current (Sink): 2A
  • High Side Voltage: 600V (max)
  • Package Type: 16-SOIC
  • Operating Temperature Range: -40°C to 150°C
  • Supply Voltage Range: 3.3V to 20V
  • Rise Time: 25ns
  • Fall Time: 17ns
