IRF1104PBF Infineon Technologies IRF1104PBF label picture 2 IRF1104PBF real image IRF1104PBF real image 2
Same model may have multiple batches, images only for reference.
IRF1104PBF Infineon Technologies IRF1104PBF label picture 2 IRF1104PBF real image IRF1104PBF real image 2
IRF1104PBF Infineon Technologies IRF1104PBF label picture 2 IRF1104PBF real image IRF1104PBF real image 2
Same model may have multiple batches, images only for reference.

IRF1104PBF

Part No IRF1104PBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 40V 100A TO-220AB
Datasheet
IRF1104PBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube/Rail
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 40V
Continuous Drain Current at 25°C 100A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 93nC @ 10V
Max Input Capacitance 2900pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 170W (Tc)
Maximum Rds On at Id,Vgs 9 mOhm @ 60A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting Through Hole
Case / Package TO-220AB
Dimension TO-220-3
Win Source Part Number 017410-IRF1104PBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian IRF1104PBF CAD Model

Description

The Infineon Technologies IRF1104PBF is a powerful MOSFET transistor designed for use in high power electronic circuits.

  • Power Dissipation (Max): 170W (Tc)
  • Continuous Drain Current: 100A (Tc) @ 25°C
  • Type: N-channel
  • Drain-Source Breakdown Voltage: 40V
  • Gate-Source Threshold Voltage: 4V @ 250μA
  • Max Rds On: 9 mOhm @ 60A, 10V
  • Package: TO-220AB
  • Market Availability: Open market
  • Supply and Demand: Balanced
