IRF1405S Real Image IRF1405S real image11732
Same model may have multiple batches, images only for reference.
IRF1405S Real Image IRF1405S real image11732
IRF1405S Real Image IRF1405S real image11732
Same model may have multiple batches, images only for reference.

IRF1405S

Part No IRF1405S
Manufacturer Infineon Technologies
Catalog FETs - Single
Description Power MOSFET(Vdss=55V, Rds(on)=5.3mohm, Id=131A⑥) | MOSFET N-CH 55V 131A D2PAK
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube
Status Obsolete
Transistor Polarity N-Channel
Technology MOSFET
Vds - Drain-Source Breakdown Voltage 55V
Id - Continuous Drain Current 131A
Drive Voltage (Max Rds On, Min Rds On) 10V
Rds On (Maximum) at Id, Vgs 5.3mOhm at 101A, 10V
Gate Source Voltage(th) (Maximum) at Id 4V at 250μA
Gate Charge (Qg) (Maximum) at Vgs 260nC at 10V
Gate Source Voltage (Maximum) ±20V
Input Capacitance (Ciss) (Maximum) at Vds 5480pF at 25V
Power Dissipation (Maximum) 200W
Temperature Range - Operating -55°C ~ 175°C
Mounting Style SMD
Supplier Device Package D2PAK
Manufacturer Package TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Manufacturer Pack Quantity 50
MSL Level 1 (Unlimited)
Win Source Part Number 1186903-IRF1405S
Manufacturer Homepage www.irf.com
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name IRF1405S
Introduction Date January 11, 2001
ECCN EAR99
Estimated EOL Date Obsolete
Ultra Librarian 3D Model Ultra Librarian IRF1405S CAD Model

Description

The Infineon IRF1405S is a high-popularity electronic component used in various electronic devices.

  • Technology: MOSFET
  • Win Source Part Number: 1186903
  • Transistor Polarity: N-channel
  • Introduction Date: January 11, 2001
  • Status: Obsolete
  • Manufacturer Homepage: www.irf.com
