IRF3205SPBF Infineon Technologies IRF3205SPBF label picture
Same model may have multiple batches, images only for reference.
IRF3205SPBF Infineon Technologies IRF3205SPBF label picture
IRF3205SPBF Infineon Technologies IRF3205SPBF label picture
Same model may have multiple batches, images only for reference.

IRF3205SPBF

Part No IRF3205SPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 55V 110A D2PAK
Datasheet
IRF3205SPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube/Rail
Status Not For New Designs
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 55V
Continuous Drain Current at 25°C 110A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 146nC @ 10V
Max Input Capacitance 3247pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 200W (Tc)
Maximum Rds On at Id,Vgs 8 mOhm @ 62A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package D2PAK
Dimension TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Win Source Part Number 015758-IRF3205SPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian IRF3205SPBF CAD Model

Description

The Infineon Technologies 015758-IRF3205SPBF is a high-popularity electronic component with limited supply and demand status.

  • Component Type: MOSFET technology component
  • Category: designed for use in discrete semiconductor products
  • Maximum Power Dissipation: 200W (Tc)
  • Drain-Source Breakdown Voltage: 55V
  • Recommendation: not recommended for new designs
  • Operating Temperature: -55°C to 175°C (TJ)
