Same model may have multiple batches, images only for reference.

IRF6635TRPBF

Name: IRF6635TRPBF
Brand: Infineon Technologies
SKU: 159740
Availability: InStock
Rating: 4.93 (68 reviews)

Get a Quote

Part No	IRF6635TRPBF
Manufacturer	Infineon Technologies
Catalog	FETs - Single
Description	MOSFET N-CH 30V 32A DIRECTFET / Trans MOSFET N-CH Si 30V 32A 7-Pin Direct-FET MX T/R
Datasheet	IRF6635TRPBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products
Family	Transistors - FETs, MOSFETs - Single
Manufacturer	Infineon Technologies
Series	HEXFET
Packaging	Reel(TR)
FET Type	MOSFET N-Channel, Metal Oxide
FET Feature	Standard
Drain to Source Voltage (Vdss)	30V
Current - Continuous Drain (Id) @ 25°C	32A (Ta), 180A (Tc)
Rds On (Max) @ Id, Vgs	1.8 mOhm @ 32A, 10V
Vgs(th) (Max) @ Id	2.35V @ 250μA
Gate Charge (Qg) @ Vgs	71nC @ 4.5V
Input Capacitance (Ciss) @ Vds	5970pF @ 15V
Power - Max	2.8W
Operating Temperature Range	-40°C ~ 150°C (TJ)
Mounting Style	SMD/SMT
Package	DirectFET Isometric MX
Manufacturer Device Package	DIRECTFET MX
Win Source Part Number	017470-IRF6635TRPBF
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Family Name	IRF6635
Introduction Date	May 03, 2006
ECCN	EAR99
Country of Origin	Mexico, Philippines
Halogen Free	Compliant
Estimated EOL Date	Obsolete / End of life
Ultra Librarian 3D Model	Ultra Librarian IRF6635TRPBF CAD Model

Alternative Products

Description

The supply and demand status is limited.

Product: MOSFET transistor that is designed for use in power management applications
Maximum Power Dissipation: 2.8W
Drain-Source Breakdown Voltage: 30V
Package: DirectFET Isometric MX package
Maximum Rds On @ Id,Vgs: 1.8 mOhm @ 32A, 10V
