IRF7416PbF

Part No IRF7416PbF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 30V 10A 8SO
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Transistors - FETs, MOSFETs - Single FETs, MOSFETs
Mfr Infineon Technologies
Series HEXFET®
Package Tube
Product Status Discontinued
FET Type P-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 30 V
Current - Continuous Drain (Id) @ 25°C 10A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Rds On (Max) @ Id, Vgs 20mOhm @ 5.6A, 10V
Vgs(th) (Max) @ Id 1V @ 250µA
Gate Charge (Qg) (Max) @ Vgs 92 nC @ 10 V
Vgs (Max) ±20V
Input Capacitance (Ciss) (Max) @ Vds 1700 pF @ 25 V
Power Dissipation (Max) 2.5W (Ta)
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Surface Mount
Supplier Device Package 8-SO
Package / Case 8-SOIC (0.154", 3.90mm Width)
Standard Package 95 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.29.0095
Win Source Part Number 159932-IRF7416PbF
Ultra Librarian 3D Model Ultra Librarian IRF7416PbF CAD Model

Description

IRF7416PbF from Infineon Technologies is a MOSFET device listed in the Transistors - FETs, MOSFETs - RF category and is typically considered for switching and signal-control roles in compact electronic designs. Engineers may evaluate this part for power management stages, load switching, portable equipment, telecom-related hardware, and other designs where efficient MOSFET performance and established supplier support are important. As an Infineon component, it is positioned as a practical choice for designers seeking a recognized manufacturer with broad semiconductor application coverage. The lifecycle status for IRF7416PbF is currently information not available, so design teams should confirm current production status directly through Infineon or authorized distribution before committing to new programs or long-term service builds. RoHS compliance information is also not available from the provided input. Because environmental compliance can affect qualification, export, and customer acceptance, engineers and procurement teams should verify the latest RoHS and material declaration data using the official datasheet or manufacturer compliance documentation.
