IRF9328TRPBF Real Image IRF9328TRPBF real image10308 IRF9328TRPBF real image10309 IRF9328TRPBF Real Image
Same model may have multiple batches, images only for reference.
IRF9328TRPBF Real Image IRF9328TRPBF real image10308 IRF9328TRPBF real image10309 IRF9328TRPBF Real Image
IRF9328TRPBF Real Image IRF9328TRPBF real image10308 IRF9328TRPBF real image10309 IRF9328TRPBF Real Image
Same model may have multiple batches, images only for reference.

IRF9328TRPBF

Part No IRF9328TRPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 30V 12A 8-SOIC
Datasheet
IRF9328TRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 12A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2.4V @ 25μA
Max Gate Charge 52nC @ 10V
Max Input Capacitance 1680pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 2.5W (Ta)
Maximum Rds On at Id,Vgs 11.9 mOhm @ 12A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SO
Dimension 8-SOIC (0.154", 3.90mm Width)
Win Source Part Number 1046768-IRF9328TRPBF
Family Name IRF9328
Introduction Date May 26, 2010
ECCN EAR99
Country of Origin China, Thailand
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian IRF9328TRPBF CAD Model

Description

Infineon Technologies IRF9328TRPBF is a P-channel MOSFET that has a maximum power dissipation of 2.5W (Ta) and a drain-source breakdown voltage of 30V.

  • Continuous Drain Current: 12A (Tc)
  • Maximum Rds On: 11.9 mOhm @ 12A, 10V
  • Gate-Source Threshold Voltage: 2.4V @ 25μA
  • Maximum Gate Charge: 52nC @ 10V
  • Package: 8-SO
  • Dimension: 8-SOIC (0.154", 3.90mm Width)
  • Lifecycle Status: Active
  • Temperature Range: -55°C to 150°C (TJ)
