Same model may have multiple batches, images only for reference.

IRF9Z34NSTRRPBF

Name: IRF9Z34NSTRRPBF
Brand: Infineon Technologies
SKU: 160234
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

Part No	IRF9Z34NSTRRPBF
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET P-CH 55V 19A D2PAK
Datasheet	IRF9Z34NSTRRPBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Reel - TR
Status	Not For New Designs
Polarity	P-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	55V
Continuous Drain Current at 25°C	19A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Gate-Source Threshold Voltage	4V @ 250μA
Max Gate Charge	35nC @ 10V
Max Input Capacitance	620pF @ 25V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	3.8W (Ta), 68W (Tc)
Maximum Rds On at Id,Vgs	100 mOhm @ 10A, 10V
Temperature Range - Operating	-55°C to 175°C (TJ)
Mounting	SMD (SMT)
Case / Package	D2PAK
Dimension	TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Win Source Part Number	069442-IRF9Z34NSTRRPBF
Popularity	Medium
Supply and Demand Status	Sufficient
Ultra Librarian 3D Model	Ultra Librarian IRF9Z34NSTRRPBF CAD Model

Alternative Products

Description

The Infineon Technologies IRF9Z34NSTRRPBF is a P-channel MOSFET with a drain-source breakdown voltage of 55V and a continuous drain current @ 25°C of 19A (Tc).

Gate-Source Threshold Voltage: 4V @ 250μA
Maximum Gate Charge: 35nC @ 10V
Maximum Input Capacitance: 620pF @ 25V
Maximum Gate-Source Voltage: ±20V
Packaging: D2PAK
Status: not for new designs
