IRFB4115PBF

Part No IRFB4115PBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 150V 104A TO220AB
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube/Rail
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 150V
Continuous Drain Current at 25°C 104A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 5V @ 250μA
Max Gate Charge 120nC @ 10V
Max Input Capacitance 5270pF @ 50V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 380W (Tc)
Maximum Rds On at Id,Vgs 11 mOhm @ 62A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting Through Hole
Case / Package TO-220AB
Dimension TO-220-3
Win Source Part Number 069453-IRFB4115PBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian IRFB4115PBF CAD Model

Description

IRFB4115PBF from Infineon Technologies is a MOSFET device used in power switching and control designs where engineers need reliable semiconductor performance from a recognized supplier. It is commonly evaluated for use in power conversion stages, motor drive sections, switching circuits, and other high-efficiency electronic designs, depending on the exact electrical requirements confirmed in the official datasheet. For procurement teams and design engineers, the part’s value is tied to Infineon’s strong market presence and broad acceptance in industrial and embedded hardware programs. The current lifecycle status for IRFB4115PBF is information not available, so teams should confirm whether it is active, not recommended for new designs, or approaching end-of-life before committing to production. RoHS compliance information is also not available in the provided data. Engineers, compliance teams, and buyers should verify the latest environmental status, material declarations, and qualification details directly through Infineon documentation or authorized distribution sources.
