IRFP4768PBF Real Image IRFP4768PBF label picture IRFP4768PBF Real Image
Same model may have multiple batches, images only for reference.
IRFP4768PBF Real Image IRFP4768PBF label picture IRFP4768PBF Real Image
IRFP4768PBF Real Image IRFP4768PBF label picture IRFP4768PBF Real Image
Same model may have multiple batches, images only for reference.

IRFP4768PBF

Part No IRFP4768PBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description Trans MOSFET N-CH 250V 93A 3-Pin(3+Tab) TO-247AC Tube / MOSFET N-CH 250V 93A TO-247AC
Datasheet
IRFP4768PBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube/Rail
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 250V
Continuous Drain Current at 25°C 93A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 5V @ 250μA
Max Gate Charge 270nC @ 10V
Max Input Capacitance 10880pF @ 50V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 520W (Tc)
Maximum Rds On at Id,Vgs 17.5 mOhm @ 56A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting Through Hole
Case / Package TO-247AC
Dimension TO-247-3
Win Source Part Number 205380-IRFP4768PBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name IRFP4768
Introduction Date February 26, 2009
ECCN EAR99
Country of Origin China, Mexico
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian IRFP4768PBF CAD Model

Description

The Infineon Technologies IRFP4768PBF is a N-Channel MOSFET transistor with a maximum power dissipation of 520W (Tc).

  • Mounting: Through-hole mounting
  • Package: TO-247AC case
  • Drain-Source Breakdown Voltage: 250V
  • Continuous Drain Current: 93A @ 25°C
  • Gate-Source Threshold Voltage: 5V @ 250μA
  • Maximum Gate Charge: 270nC @ 10V
  • Maximum Input Capacitance: 10880pF @ 50V
  • Maximum Rds On at Id,Vgs: 17.5 mOhm @ 56A, 10V
  • Temperature Range: -55°C to 175°C (TJ)
  • Compliance: Halogen-free regulations
  • Supply and Demand Status: balanced
  • Estimated EOL date: 2027
