IRFR220NTRPBF Real Image IRFR220NTRPBF real image357
Same model may have multiple batches, images only for reference.
IRFR220NTRPBF Real Image IRFR220NTRPBF real image357
IRFR220NTRPBF Real Image IRFR220NTRPBF real image357
Same model may have multiple batches, images only for reference.

IRFR220NTRPBF

Part No IRFR220NTRPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 200V 5A DPAK
Datasheet
IRFR220NTRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 200V
Continuous Drain Current at 25°C 5A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 23nC @ 10V
Max Input Capacitance 300pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 43W (Tc)
Maximum Rds On at Id,Vgs 600 mOhm @ 2.9A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package D-Pak
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 017664-IRFR220NTRPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian IRFR220NTRPBF CAD Model

Description

The Infineon Technologies MOSFET is a N-Channel power transistor with a maximum power dissipation of 43W and a drain-source breakdown voltage of 200V.

  • Maximum Continuous Drain Current: 5A @ 25°C
  • Maximum Rds On: 600 mOhm @ 2.9A, 10V
  • Gate-Source Threshold Voltage: 4V @ 250μA
  • Maximum Gate Charge: 23nC @ 10V
  • Maximum Input Capacitance: 300pF @ 25V
  • Package: D-Pak
  • Field of Application: Discrete semiconductor products
