IRFS7430TRL7PP Real Image IRFS7430TRL7PP Real Image
Same model may have multiple batches, images only for reference.
IRFS7430TRL7PP Real Image IRFS7430TRL7PP Real Image
IRFS7430TRL7PP Real Image IRFS7430TRL7PP Real Image
Same model may have multiple batches, images only for reference.

IRFS7430TRL7PP

Part No IRFS7430TRL7PP
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 40V 240A D2PAK / Trans MOSFET N-CH Si 40V 522A 7-Pin(6+Tab) D2PAK T/R
Datasheet
IRFS7430TRL7PP Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Series HEXFET, StrongIRFET
Packaging Reel package
Channel Type Type N
Technology MOSFET
Drain Source Voltage 40V
Current - Continuous Drain (Id) @ 25°C 240A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 6V, 10V
Vgs(th) (Maximum) @ Id 3.9V @ 250μA
Gate Charge (Qg) (Maximum) @ Vgs 460nC @ 10V
Input Capacitance (Ciss) (Maximum) @ Vds 13975pF @ 25V
Vgs (Maximum) ±20V
Power Dissipation (Maximum) 375W (Tc)
Rds On (Maximum) @ Id, Vgs 0.75 mOhm @ 100A, 10V
Operating Temperature Range -55°C ~ 175°C (TJ)
Mounting SMD
Manufacturer Package D2PAK (7-Lead)
Package TO-263-7, D2Pak (6 Leads + Tab)
Win Source Part Number 777074-IRFS7430TRL7PP
Popularity Medium
Supply and Demand Status Limited
Family Name IRFS7430
ECCN EAR99
Country of Origin China, Mexico
Halogen Free Compliant
Estimated EOL Date 2029
Ultra Librarian 3D Model Ultra Librarian IRFS7430TRL7PP CAD Model

Description

The Infineon Technologies 777074-IRFS7430TRL7PP is a HEXFET and StrongIRFET MOSFET discrete semiconductor product with a channel type of N and a drain-source voltage of 40V.

  • Channel Type: N
  • Drain-Source Voltage: 40V
  • Current-Continuous Drain: 240A (Tc) @ 25°C
  • Power Dissipation: 375W (Tc)
  • Mounting: SMD
  • Package: TO-263-7, D2Pak (6 Leads + Tab)
  • Gate Charge: 460nC @ 10V
  • Input Capacitance: 13975pF @ 25V
  • ECCN: EAR99
  • Supply and Demand Status: Limited
