IRL1004S

Name: IRL1004S
Brand: Infineon Technologies
SKU: 462594
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

Part No	IRL1004S
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 40V 130A D2PAK
Datasheet	IRL1004S Datasheet
Sample
Rohs State	Need to verify
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Tube/Rail
Status	Obsolete(EOL)
Polarity	N-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	40V
Continuous Drain Current at 25°C	130A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Gate-Source Threshold Voltage	1V @ 250μA
Max Gate Charge	100nC @ 4.5V
Max Input Capacitance	5330pF @ 25V
Maximum Gate-Source Voltage	±16V
Power Dissipation (Max)	3.8W (Ta), 200W (Tc)
Maximum Rds On at Id,Vgs	6.5 mOhm @ 78A, 10V
Temperature Range - Operating	-55°C to 175°C (TJ)
Mounting	SMD (SMT)
Case / Package	D2PAK
Dimension	TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Win Source Part Number	1047414-IRL1004S
Popularity	Medium
Supply and Demand Status	Sufficient
Ultra Librarian 3D Model	Ultra Librarian IRL1004S CAD Model

Alternative Products

Description

The Infineon Technologies IRL1004S MOSFET is a surface-mount device with an N-channel polarity and a drain-source breakdown voltage of 40V.

Polarity: N-channel
Drain-Source Breakdown Voltage: 40V
Continuous Drain Current: 130A @ 25°C (Tc)
Maximum Power Dissipation: 3.8W (Ta) or 200W (Tc)
Gate-Source Threshold Voltage: 1V @ 250μA
Maximum Gate Charge: 100nC @ 4.5V
Package: D2PAK
Operating Temperature: -55°C to 175°C (TJ)
Category: Discrete Semiconductor Products
Status: Obsolete (EOL)
