IRLH5030TRPBF Real Image IRLH5030TRPBF Real Image
Same model may have multiple batches, images only for reference.
IRLH5030TRPBF Real Image IRLH5030TRPBF Real Image
IRLH5030TRPBF Real Image IRLH5030TRPBF Real Image
Same model may have multiple batches, images only for reference.

IRLH5030TRPBF

Part No IRLH5030TRPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 100V 13A 8PQFN
Datasheet
IRLH5030TRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 100V
Continuous Drain Current at 25°C 13A (Ta), 100A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2.5V @ 150μA
Max Gate Charge 94nC @ 10V
Max Input Capacitance 5185pF @ 50V
Maximum Gate-Source Voltage ±16V
Power Dissipation (Max) 3.6W (Ta), 156W (Tc)
Maximum Rds On at Id,Vgs 9 mOhm @ 50A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package PQFN (5x6)
Dimension 8-PowerVDFN
Win Source Part Number 069712-IRLH5030TRPBF
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian IRLH5030TRPBF CAD Model

Description

The Infineon Technologies 069712-IRLH5030TRPBF is a high-performance N-channel MOSFET that can be used in a variety of applications.

  • Drain-Source Breakdown Voltage: 100V
  • Maximum Continuous Drain Current: 13A (Ta), 100A (Tc) @ 25°C
  • Gate-Source Threshold Voltage: 2.5V @ 150μA
  • Maximum Rds On at Id,Vgs: 9 mOhm @ 50A, 10V
  • Maximum Gate-Source Voltage: ±16V
  • Maximum Input Capacitance: 5185pF @ 50V
  • Maximum Gate Charge: 94nC @ 10V
  • Package: PQFN (5x6) case
  • Power Dissipation: 3.6W (Ta), 156W (Tc)
