IRS21864STRPBF

Name: IRS21864STRPBF
Brand: Infineon Technologies
SKU: 161846
Availability: InStock
Rating: 4.93 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IRS21864STRPBF
Manufacturer	Infineon Technologies
Catalog	PMIC - Gate Drivers
Description	Driver 600V 4A 2-OUT High and Low Side Non-Inv 14-Pin SOIC N T/R / IC DRIVER HI/LO SIDE 600V 14SOIC
Datasheet	IRS21864STRPBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Infineon Technologies
Packaging	Reel - TR
Status	Active
Driven Configuration	Half-Bridge
Channel Type	Independent
Number of Drivers	2
Gate Type	IGBT, N-Channel MOSFET
Supply Voltage - Operating	10 V to 20 V
Logic Voltage - VIL, VIH	0.8V, 2.5V
Current - Peak Output (Source, Sink)	4A, 4A
Input Type	Non-Inverting
High Side Voltage - Max (Bootstrap)	600V
Rise and Fall Time	22ns, 18ns
Temperature Range - Operating	-40°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	14-SOIC
Win Source Part Number	017832-IRS21864STRPBF
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Family Name	IRS21864
Introduction Date	May 04, 2006
ECCN	EAR99
Country of Origin	China , Thailand
Halogen Free	Compliant
Estimated EOL Date	2025
Ultra Librarian 3D Model	Ultra Librarian IRS21864STRPBF CAD Model

Alternative Products

Description

The Infineon Technologies IRS21864STRPBF is a high-performance integrated circuit designed for use in a variety of applications.

Supply Voltage: 10 V to 20 V
Channel Type: Independent channel type
Input Type: Non-inverting
Driven Configuration: Half-bridge
Gate Type: IGBT, N-Channel MOSFET
Logic Voltage: VIL, VIH: 0.8V, 2.5V
Rise Time: 22ns
Fall Time: 18ns
Mounting: SMD (SMT)
Package: 14-SOIC
