The IS25LQ020B is a 2Mb Serial Flash memory device. It is a CMOS Flash memory device accessed by a high-speed SPI-compatible bus. The device provides a serial interface allowing simple connection to microcontrollers and microprocessors.

Applications

• Consumer Electronics
• Industrial Control
• Medical Devices
• Networking Equipment
• Automotive Systems

Features

• 2Mb (262,144 x 8) Flash Memory
• Standard SPI and Dual SPI
• High Speed Clock Frequency: 104MHz
• Low Power Consumption
• Single Power Supply: 2.3V to 3.6V
• Industrial Temperature Range: -40°C to +85°C
• Small Package Options

Benefits

• Simplified board layout and reduced system cost due to serial interface.
• Fast data transfer rates improve system performance.
• Low power consumption extends battery life in portable applications.
• Reliable data storage over a wide temperature range.
• Space-saving package options for compact designs.

Additional Details

The IS25LQ020B supports standard SPI (Serial Peripheral Interface) and Dual SPI operation, providing flexibility in system design. It offers a wide operating voltage range and low power consumption, making it suitable for a variety of applications. The device includes features such as sector protection and password protection to ensure data security.

Key Specifications:

• Memory Size: 2Mb
• Interface: SPI, Dual SPI
• Clock Frequency: 104 MHz (Maximum)
• Operating Voltage: 2.3V - 3.6V
• Operating Temperature: -40°C to +85°C
• Package: SOIC-8, WSON-8
