The 60EPS12PBF is a 60A, 1200V standard recovery rectifier diode manufactured by International Rectifier (now Infineon Technologies). It is designed for use in various high-voltage, high-current applications where a fast switching speed is not critical. This diode offers a robust and reliable solution for rectification purposes.

Applications:

• Input rectification for AC-DC power supplies.
• Free-wheeling diodes in inductive circuits.
• Motor control circuits.
• Uninterruptible power supplies (UPS).
• Welding equipment.

Features:

• High surge current capability.
• Standard recovery time.
• High voltage rating (1200V).
• Low forward voltage drop.
• RoHS compliant.
• Available in a variety of package styles.

Benefits:

• Provides reliable rectification in high-voltage applications.
• Suitable for applications with high inrush currents.
• Reduces power dissipation due to its low forward voltage drop.
• Offers a cost-effective solution for standard recovery rectification needs.
• Environmentally friendly due to RoHS compliance.

Technical Specifications:

The 60EPS12PBF features a maximum average forward current of 60A. The peak forward surge current can reach up to 650A. The maximum reverse recovery time is typically around 5µs. It operates within a temperature range of -40°C to +150°C. The forward voltage drop is typically around 1.2V at the rated current. This diode is commonly packaged in a TO-247AC package, ensuring efficient heat dissipation.

This diode is often selected for its robust performance characteristics and its ability to handle demanding electrical conditions. Its high surge current capability makes it well-suited for applications where large transient currents are present. The 60EPS12PBF diode provides a balance of performance and cost-effectiveness, making it a suitable choice for a variety of industrial and commercial power applications.
