ISL26132AVZ Real Image ISL26132AVZ Real Image
Same model may have multiple batches, images only for reference.
ISL26132AVZ Real Image ISL26132AVZ Real Image
ISL26132AVZ Real Image ISL26132AVZ Real Image
Same model may have multiple batches, images only for reference.

ISL26132AVZ

Part No ISL26132AVZ
Manufacturer Intersil
Catalog Data Acquisition - Analog to Digital Converters (ADC)
Description IC ADC 24BIT SRL 80SPS 24TSSOP
Datasheet
ISL26132AVZ Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Intersil
Packaging Reel - TR
Status Active
Number of Bits 24
Sampling Rate 80
Number of Inputs 2
Input Type Differential
Data Interface SPI
Configuration MUX-PGA-ADC
Number of A/D Converters 1
Reference Type External, Internal
Analog Supply Voltage 5V
Digital Supply Voltage 2.7 V to 5.25 V
Features PGA
Temperature Range - Operating -40°C to 105°C
Case / Package 24-TSSOP
Win Source Part Number 069887-ISL26132AVZ
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ISL26132AVZ CAD Model

Description

The Intersil ISL26132AVZ is a high-quality integrated circuit that is designed to provide reliable performance in a wide range of applications.

  • Features: Programmable gain amplifier (PGA), multiplexer (MUX), analog-to-digital converter (ADC)
  • Inputs: Two differential
  • Bits: 24
  • Data Interface: SPI
  • Package: 24-TSSOP
  • Temperature Range: -40°C to 105°C
  • Analog Supply Voltage: 5V
  • Digital Supply Voltage: 2.7 V to 5.25 V
  • Supply and Demand Status: Limited
