Same model may have multiple batches, images only for reference.

IXFN340N07

Name: IXFN340N07
Brand: IXYS
SKU: 988453
Availability: InStock
Rating: 4.93 (48 reviews)

Get a Quote

Part No	IXFN340N07
Manufacturer	IXYS
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 70V 340A SOT-227B / N-Channel 70 V 340A (Tc) 700W (Tc) Chassis Mount SOT-227B
Datasheet	IXFN340N07 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products>Transistors - FETs, MOSFETs - Single
Mfr	IXYS
Series	HiPerFET™
Package	Tube
Product Status	Obsolete
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	70 V
Current - Continuous Drain (Id) @ 25°C	340A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Rds On (Max) @ Id, Vgs	4mOhm @ 100A, 10V
Vgs(th) (Max) @ Id	4V @ 8mA
Gate Charge (Qg) (Max) @ Vgs	490 nC @ 10 V
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	12200 pF @ 25 V
Power Dissipation (Max)	700W (Tc)
Temperature Range - Operating	-55°C ~ 150°C (TJ)
Mounting Type	Chassis Mount
Supplier Device Package	SOT-227B
Package / Case	SOT-227-4, miniBLOC
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.29.0095
Standard Package	10
Win Source Part Number	988453-IXFN340N07
Ultra Librarian 3D Model	Ultra Librarian IXFN340N07 CAD Model

Alternative Products

Description

The IXFN340N07 is an N-Channel MOSFET transistor from IXYS in the HiPerFET series.

Manufacturer: IXYS
Product: IXFN340N07
Type: N-Channel MOSFET Transistor
Series: HiPerFET
Drain to Source Voltage (Max): 70 V
Continuous Drain Current: 340A @ 25°C
Rds On (Max) @ Id, Vgs: 4mOhm @ 100A, 10V
Vgs(th) (Max) @ Id: 4V @ 8mA
Gate Charge (Qg) (Max) @ Vgs: 490 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 12200 pF @ 25 V
Package: SOT-227-4, miniBLOC
Mounting: Chassis
Suitable For: Power supplies and motor drives
