IXTV26N50P Real Image
Same model may have multiple batches, images only for reference.

IXTV26N50P

Part No IXTV26N50P
Manufacturer IXYS
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 500V 26A PLUS220 / N-Channel 500 V 26A (Tc) 460W (Tc) Through Hole PLUS220
Datasheet
IXTV26N50P Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Transistors - FETs, MOSFETs - Single FETs, MOSFETs
Mfr IXYS
Series PolarHV™
Package Tube
Product Status Obsolete
FET Type N-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 500 V
Current - Continuous Drain (Id) @ 25°C 26A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Rds On (Max) @ Id, Vgs 230mOhm @ 13A, 10V
Vgs(th) (Max) @ Id 5.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs 65 nC @ 10 V
Vgs (Max) ±30V
Input Capacitance (Ciss) (Max) @ Vds 3600 pF @ 25 V
Power Dissipation (Max) 460W (Tc)
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Through Hole
Supplier Device Package PLUS220
Package / Case TO-220-3, Short Tab
Base Product Number IXTV26
Standard Package 50
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.29.0095
Win Source Part Number 1346804-IXTV26N50P
Ultra Librarian 3D Model Ultra Librarian IXTV26N50P CAD Model

Description

The IXTV26N50P is an N-channel MOSFET transistor from the PolarHV series, designed for use in discrete semiconductor products such as FETs and MOSFETs.

  • Drain-to-Source Voltage: 500V
  • Power Dissipation: 460W
  • Mounting Type: Through-Hole
  • Package: TO-220-3, Short Tab
  • Operating Temperature: -55°C to 150°C
  • Continuous Drain Current (Id): 26A (Tc)
  • Maximum Rds On: 230mOhm @ 13A, 10V
  • Gate Charge: 65 nC @ 10 V
  • Input Capacitance: 3600 pF @ 25 V
