IXTV96N25T Real Image
Same model may have multiple batches, images only for reference.

IXTV96N25T

Part No IXTV96N25T
Manufacturer IXYS
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 250V 96A PLUS220 / N-Channel 250 V 96A (Tc) 625W (Tc) Through Hole PLUS220
Datasheet
IXTV96N25T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Transistors - FETs, MOSFETs - Single FETs, MOSFETs
Mfr IXYS
Series Trench
Package Tube
FET Type N-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 250 V
Current - Continuous Drain (Id) @ 25°C 96A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Rds On (Max) @ Id, Vgs 29mOhm @ 500mA, 10V
Vgs(th) (Max) @ Id 5V @ 1mA
Gate Charge (Qg) (Max) @ Vgs 114 nC @ 10 V
Vgs (Max) ±30V
Input Capacitance (Ciss) (Max) @ Vds 6100 pF @ 25 V
Power Dissipation (Max) 625W (Tc)
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Through Hole
Supplier Device Package PLUS220
Package / Case TO-220-3, Short Tab
Base Product Number IXTV96
Standard Package 50
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.29.0095
California Prop 65 Warning Information
Win Source Part Number 1346662-IXTV96N25T
Ultra Librarian 3D Model Ultra Librarian IXTV96N25T CAD Model

Description

The IXTV96N25T is an N-channel MOSFET transistor that is designed to be used in discrete semiconductor products.

  • FET Type: Single FET
  • Series: Trench
  • Drain to Source Voltage (Vdss): 250 V
  • Power Dissipation (Max): 625W (Tc)
  • Mounting Type: Through Hole
  • Package / Case: TO-220-3, Short Tab
  • Vgs (Max): ±30V
  • Temperature Range: -55°C to 150°C (TJ)
  • Input Capacitance (Ciss) (Max) @ 25 V: 6100 pF @ 25 V
  • Current - Continuous Drain (Id) @ 25°C: 96A (Tc)
  • Rds On (Max) @ Id, Vgs: 29mOhm @ 500mA, 10V
  • Vgs(th) (Max) @ Id: 5V @ 1mA
  • Gate Charge (Qg) (Max) @ Vgs: 114 nC @ 10 V
