IXXK300N60B3

Part No IXXK300N60B3
Manufacturer IXYS
Catalog IGBTs - Single
Description IGBT PT 600V 550A TO-264
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

IGBT Type PT
Voltage - Collector Emitter Breakdown (Max) 600 V
Current - Collector (Ic) (Max) 550 A
Current - Collector Pulsed (Icm) 1140 A
Vce(on) (Max) @ Vge, Ic 1.6V @ 15V, 100A
Power - Max 2300 W
Switching Energy 3.45mJ (on), 2.86mJ (off)
Input Type Standard
Gate Charge 460 nC
Td (on/off) @ 25°C 50ns/190ns
Test Condition 400V, 100A, 1Ohm, 15V
Temperature Range - Operating -55°C ~ 175°C (TJ)
Mounting Type Through Hole
Case / Package TO-264-3, TO-264AA
Supplier Device Package TO-264 (IXXK)
Package Tube
Supply and Demand Status Shortage
Win Source Part Number 1495055-IXXK300N60B3
Ultra Librarian 3D Model Ultra Librarian IXXK300N60B3 CAD Model

Description
