The IL-Z-2S-S125C3 is a 2-position, single-row, crimp style connector manufactured by JAE Electronics. It is part of the IL-Z series, designed for compact and reliable wire-to-board connections. This connector is commonly used in various electronic devices and equipment where space is limited and secure connections are required.

Applications

• Consumer electronics
• Industrial equipment
• Automotive electronics
• Medical devices
• Lighting systems

Features

• Compact design
• Crimp style termination
• Single row configuration
• Secure locking mechanism
• Durable construction
• RoHS compliant

Benefits

• Saves space on the circuit board, enabling smaller and more compact devices.
• Provides a reliable and secure connection between wires and the board.
• Simplifies wiring and reduces the overall size of the connection.
• Ensures a stable and vibration-resistant connection, preventing accidental disconnections.
• Withstands harsh environments and provides long-term reliability.
• Environmentally friendly due to RoHS compliance.

Additional Details

The IL-Z-2S-S125C3 connector is designed for use with a specific wire gauge range and requires a compatible crimping tool for proper termination. The housing is typically made of a durable plastic material that provides insulation and protection for the contacts. The contacts themselves are usually made of a copper alloy with a plating finish, such as tin or gold, to ensure good conductivity and resistance to corrosion. The locking mechanism provides a positive latching force, preventing accidental disconnection due to vibration or mechanical stress. This connector is widely used in applications where a small, reliable, and cost-effective wire-to-board connection is required.
