SM15B-SRSS-TB

Name: SM15B-SRSS-TB
Brand: JST Sales America Inc.
SKU: 668091
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	SM15B-SRSS-TB
Manufacturer	JST Sales America Inc.
Catalog	Rectangular Connectors
Description	CONN HEADER SMD R/A 15POS 1MM
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Connectors, Interconnects - Rectangular Connectors - Headers, Male Pins
Mfr	JST Sales America Inc.
Series	SH/SR
Package	Tape & Reel (TR)Cut Tape (CT)
Product Status	Obsolete
Connector Type	Header
Contact Type	Male Pin
Pitch - Mating	0.039" (1.00mm)
Number of Positions	15
Number of Rows	1
Number of Positions Loaded	All
Style	Board to Cable/Wire
Shrouding	Shrouded - 4 Wall
Mounting Type	Surface Mount, Right Angle
Termination	Solder
Fastening Type	Push-Pull
Insulation Height	0.114" (2.90mm)
Contact Shape	Square
Contact Finish - Mating	Tin-Lead
Contact Finish - Post	Tin-Lead
Contact Material	Copper Alloy
Insulation Material	Polyamide (PA), Nylon
Features	Solder Retention
Temperature Range - Operating	-25°C ~ 85°C
Material Flammability Rating	UL94 V-0
Insulation Color	Natural
Current Rating (Amps)	1A
Voltage Rating	50V
Standard Package	3,000 pcs
MSL Level	1 (Unlimited)
ECCN	EAR99
HTSUS	8536.69.4040
Win Source Part Number	668091-SM15B-SRSS-TB
Ultra Librarian 3D Model	Ultra Librarian SM15B-SRSS-TB CAD Model

Alternative Products

Description

The 668091-SM15B-SRSS-TB is a male pin header connector from the SH/SR series of rectangular connectors.

Positions: 15
Termination: Solder
Material: Copper alloy
Voltage Rating: 50V
Flammability Rating: UL94 V-0
Insulation Material: Polyamide (PA), nylon
Pitch: 0.039" (1.00mm)
Contact Finish: Tin-lead
Shrouded: 4 Walls
Mounting Type: Surface Mount, Right Angle
Application Style: Board to Cable/Wire
Operating Temperature: -25°C to 85°C
Contact Shape: Square
Contact Length: Not Specified
Status: Obsolete
Standard Package: 3,000 pcs
