The ISPLSI 1016E-80LTN44I is a high-performance Complex Programmable Logic Device (CPLD) from Lattice Semiconductor. It is designed to provide flexible logic solutions for a wide range of digital applications. With its in-system programmability (ISP) and advanced architecture, it offers designers a versatile and efficient way to implement custom logic functions.

Applications:

• Address Decoding
• Glue Logic
• State Machine Implementation
• Peripheral Control
• Interface Logic

Features:

• In-System Programmability (ISP): Allows for easy programming and reprogramming of the device after it has been mounted on the circuit board.
• High Performance: Offers fast propagation delays for high-speed operation.
• Flexible Architecture: Provides a configurable logic structure to accommodate a variety of digital designs.
• Low Power Consumption: Designed for energy-efficient operation, suitable for portable and battery-powered applications.
• 44-Pin Package: Compact package size for space-constrained designs.
• 80 MHz Operating Frequency: Supports high-speed system clocks.

Benefits:

• Design Flexibility: Customizable logic implementation allows designers to tailor the device to specific application requirements.
• Reduced Time-to-Market: In-system programmability enables rapid prototyping and design iterations.
• Improved System Performance: High-speed operation enhances overall system performance.
• Lower Power Consumption: Energy-efficient design extends battery life in portable devices.
• Simplified Board Layout: Compact package size reduces board space requirements and simplifies routing.

Additional Details:

The ISPLSI 1016E-80LTN44I operates from a 5V power supply. It is based on a CMOS E2CMOS technology, ensuring low power consumption and high reliability. The device features a programmable interconnect array, which provides flexible routing of signals between logic blocks. The internal architecture comprises of logic blocks and I/O blocks, facilitating the implementation of a wide variety of digital circuits. It is commonly used to replace discrete logic gates, reducing component count and improving system reliability. The device is programmed using industry-standard programming tools. Its operating temperature range is typically 0°C to +70°C. The 44-LTN package is a thin quad flat pack (TQFP) which helps with thermal management.
