LCMX02-1200HC-4TG144I

Part No LCMX02-1200HC-4TG144I
Manufacturer Lattice Semiconductor Corporation
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Reference Date Code 2017+
Reference case QFP144
Manufacturer Lattice Semiconductor Corporation
Manufacturer Homepage www.latticesemi.com
Win Source Part Number 739236-LCMX02-1200HC-4TG144I
Popularity Low
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LCMX02-1200HC-4TG144I CAD Model

Description

The LCMX02-1200HC-4TG144I is a Field-Programmable Gate Array (FPGA) from the Lattice Semiconductor MachXO2 family. It's designed to provide flexible and programmable logic for a wide range of applications. This FPGA is characterized by its low power consumption, instant-on performance, and high I/O count, making it suitable for portable devices, consumer electronics, and industrial applications.

Applications

  • Consumer Electronics: Display controllers, interface bridging, and custom logic functions in TVs, set-top boxes, and mobile devices.
  • Industrial Automation: Programmable logic controllers (PLCs), motor control, and sensor interfaces.
  • Automotive: In-vehicle networking, driver assistance systems, and infotainment.
  • Communication Equipment: Interface controllers, signal processing, and protocol conversion in routers, switches, and base stations.
  • Medical Devices: Image processing, data acquisition, and control functions in medical equipment.

Features

  • 1200 Look-Up Tables (LUTs): Provides programmable logic resources for implementing custom digital circuits.
  • High I/O Count (144 pins): Offers a large number of input/output pins for connecting to external devices.
  • Low Power Consumption: Designed for energy-efficient operation, extending battery life in portable applications.
  • Instant-On Performance: Starts up quickly, enabling fast system boot times.
  • Embedded Memory: Includes on-chip memory blocks for data storage and processing.
  • Flexible I/O Standards: Supports a wide range of I/O standards, including LVCMOS, LVTTL, and SSTL.
  • Security Features: Protects the FPGA configuration from unauthorized access.

Benefits

  • Design Flexibility: Allows for customization of digital circuits to meet specific application requirements.
  • Fast Time-to-Market: Reduces development time by allowing designers to quickly implement and modify designs.
  • Low Power Operation: Enables energy-efficient designs, extending battery life in portable devices.
  • Cost-Effective Solution: Provides a cost-effective alternative to custom ASICs for low- to medium-volume applications.
  • Reliable Performance: Designed for stable and reliable operation in harsh environments.

Additional Details

The LCMX02-1200HC-4TG144I is programmed using the Lattice Diamond software. The exact number of LUTs, I/O pins, and embedded memory should be verified in the official Lattice Semiconductor datasheet for this specific part number. Proper power supply decoupling and signal integrity techniques are essential for ensuring stable and reliable operation. The FPGA is typically mounted on a printed circuit board (PCB) using surface-mount technology. The thermal characteristics of the device should be considered to ensure proper heat dissipation.
