Products specifications

Categories Development Boards, Kits, Programmers
Manufacturer Linear Technology
Main Purpose Power Management, Hot Swap Controller
Embedded No
Utilized IC / Part LT4256-1
Primary Attributes Latch-Off
Secondary Attributes LED Status Indicators
Supplied Contents Board(s)
Win Source Part Number 781402-DC1354A-A
Popularity Medium
Supply and Demand Status Limited
Family Name DC1354
Introduction Date February 23, 2009
ECCN EAR99
Country of Origin United States of America
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian DC1354A-A CAD Model

Description

The DC1354A-A demonstration board is a testament to Linear Technology's commitment to innovation and excellence in power management solutions. This board is specifically designed to showcase the capabilities of the LTC®3880, a dual-phase synchronous step-down DC/DC controller with I²C-based PMBus capability for real-time monitoring and control.

Key Features

  • Dual Output Synchronous Operation: The LTC3880 at the heart of DC1354A-A enables efficient power conversion with synchronous rectification, ensuring high efficiency and reduced heat generation.
  • PMBus Interface: With the integration of the PMBus interface, users can monitor system parameters such as voltage, current, and temperature, and can also program the power supply settings using a compatible I²C interface.
  • Wide Input Voltage Range: The board operates over a wide input voltage range, making it suitable for a variety of applications from distributed power systems to telecommunications and industrial equipment.
  • Adjustable Output Voltage: The DC1354A-A provides flexibility with its adjustable output voltage, catering to the needs of different circuits and devices.
  • Robust Protection Features: The demo board includes overvoltage, undervoltage, overcurrent, and overtemperature protection, ensuring the longevity and reliability of both the board and the end application.
  • Compact Design: Despite its powerful features, the DC1354A-A is designed with a compact form factor, making it easy to integrate into a wide range of systems without occupying excessive space.

Applications

The DC1354A-A is versatile and can be used in various applications that require precise power management and monitoring, such as:

  • Datacom and Telecom Systems
  • Industrial Equipment
  • Medical Devices
  • Automotive Electronics
  • High-Density Distributed Power Systems

Whether you are a professional engineer, a system designer, or an electronics enthusiast, the DC1354A-A demonstration board from Linear Technology is an excellent tool for evaluating the performance and features of the LTC3880 controller. It provides a hands-on experience that can help streamline the design process for power management in complex electronic systems.
