Overview of LT1176CN8-5 from Linear Technology

The LT1176CN8-5 is a high-performance, low-dropout voltage regulator designed by Linear Technology for applications requiring a well-regulated power supply. This robust regulator offers a fixed output voltage of 5V, which is a common requirement for many electronic circuits, making it an essential component for a wide range of products.

Key Features

• Fixed Output Voltage: The LT1176CN8-5 provides a stable 5V output, which is crucial for consistent performance in electronic systems.
• Low Dropout Voltage: This regulator has a low dropout voltage, ensuring efficient operation even when the input voltage is close to the output voltage, thereby minimizing power loss.
• High Current Capability: It is capable of delivering up to 1.5A of output current, making it suitable for powering a wide range of devices.
• Thermal Protection: The LT1176CN8-5 includes built-in thermal shutdown to protect the device from overheating, ensuring long-term reliability.
• Overcurrent Protection: The regulator also features current limiting to safeguard itself and the load from damage due to excessive current.

Applications

The LT1176CN8-5 is versatile and can be used in various applications, including:

• Microprocessor systems
• Low-power logic supplies
• Battery-powered devices
• Peripheral power supplies

Package and Quality

The device comes in an 8-pin PDIP package, which is widely used and easy to integrate into a variety of circuit boards. Linear Technology ensures that the LT1176CN8-5 meets high-quality standards, providing reliable and consistent performance for critical applications.

In conclusion, the LT1176CN8-5 from Linear Technology is a reliable and efficient fixed voltage regulator that offers several protective features, making it an excellent choice for designers looking to ensure stability and longevity in their power supply circuits.
