LT1764AEFE#TRPBF - Low Dropout Linear Regulator

The LT1764AEFE#TRPBF is a high-performance low dropout linear regulator (LDO) from Linear Technology, designed to deliver a continuous output current of up to 3A with a dropout voltage of only 340mV at full load. This LDO is ideal for applications requiring a high current, low voltage power supply with a minimal voltage difference between the input and output.

One of the standout features of the LT1764AEFE#TRPBF is its wide input voltage range, which spans from 2.7V to 20V, making it a versatile choice for a variety of systems. The adjustable output voltage from 1.21V to 20V allows for flexibility in design, ensuring compatibility with a broad range of microprocessors and other digital loads.

The LT1764AEFE#TRPBF boasts excellent stability and can be used with low ESR ceramic capacitors, which reduces the size and cost of the overall power supply solution. Its low noise performance and fast transient response are critical for high-end communications equipment, data storage systems, and other noise-sensitive applications.

Featuring overcurrent and overtemperature protection, the LT1764AEFE#TRPBF ensures reliable operation and a long lifespan for your critical applications. The device is available in a 16-lead TSSOP package with an exposed pad for enhanced thermal performance, making it suitable for compact and thermally challenging environments.

This LDO regulator also includes a shutdown feature that reduces the supply current to less than 1µA, providing an additional power-saving advantage for battery-powered devices during idle periods. Furthermore, with its fast start-up capability, the LT1764AEFE#TRPBF is an excellent choice for systems that require quick turn-on times.

In summary, the LT1764AEFE#TRPBF from Linear Technology is a robust, high-efficiency LDO regulator that offers a compact solution with its small footprint, making it an excellent choice for a wide range of applications including portable devices, networking equipment, and industrial systems.
