LT1963AEQ-3.3#PBF Voltage Regulator

The LT1963AEQ-3.3#PBF is a high-performance, low dropout linear regulator from Linear Technology designed to provide a fixed output voltage of 3.3V. This robust component is ideal for applications requiring a low voltage supply with a high degree of stability and low noise. With its fast transient response and low dropout voltage, it is particularly suited for use in high-performance microprocessor applications, analog circuits, and RF systems.

Key Features

• Output Voltage: Fixed at 3.3V with high accuracy.
• Output Current: Capable of delivering up to 1.5A of continuous output current.
• Low Dropout Voltage: The dropout voltage is typically 340mV at full load, which allows for efficient operation even when the input voltage is close to the output voltage.
• Low Noise: Offers exceptionally low output noise, making it suitable for sensitive RF and analog circuitry.
• Stability: Stable with low ESR, ceramic output capacitors as small as 10μF, which enhances the stability and response time.
• Protection Features: Includes built-in protection features such as over-current and over-temperature protection, ensuring reliable operation under various conditions.
• Adjustable Current Limit: The internal current limit can be set via an external resistor for added flexibility and protection.
• Thermal Performance: Housed in a TO-263 package which provides excellent thermal performance.

Applications

• Power supplies for microprocessors and DSPs
• High-efficiency linear power supplies
• Post regulators for switching supplies
• Battery-powered equipment
• Low noise instrumentation

The LT1963AEQ-3.3#PBF is designed to work with a wide variety of external components, providing designers with the flexibility to tailor the performance to their specific application. It is an ideal choice for systems that require a high-quality power supply with excellent line and load regulation, fast transient response, and a wide input voltage range.
