LT3060EDC#TRPBF - Low Dropout Linear Regulator

The LT3060EDC#TRPBF is a high-performance, low dropout linear regulator (LDO) from Linear Technology, which is now part of Analog Devices. This LDO is designed to deliver a continuous output current of up to 45mA with a dropout voltage as low as 300mV at full load. It is an ideal choice for battery-powered systems, portable devices, and applications where power efficiency and minimal quiescent current are essential.

With an adjustable output from 1.2V to 20V, the LT3060EDC#TRPBF provides a versatile solution for a wide range of power supply requirements. The device operates over a wide input voltage range from 1.6V to 45V, making it suitable for various applications, from low-voltage to high-voltage systems.

The LT3060EDC#TRPBF features an internal low-noise reference, which results in a low output noise of only 30µVRMS, making it an excellent choice for sensitive RF and precision analog applications that require a clean power supply. Furthermore, its fast transient response ensures stable operation during rapid load changes, which is critical for high-performance electronics.

One of the key benefits of this LDO is its low quiescent current of only 30µA, which helps extend battery life in portable applications. In addition, the LT3060EDC#TRPBF includes thermal shutdown and current limit protection features that safeguard the device and the application circuitry from damage due to over-temperature and over-current conditions.

The device is available in a compact, low-profile (2mm x 2mm) DFN package, which is suitable for space-constrained applications. Additionally, the LT3060EDC#TRPBF is designed to be stable with low-ESR ceramic capacitors, further reducing the required board space and component cost.

Overall, the LT3060EDC#TRPBF from Linear Technology is a robust and reliable LDO that offers excellent performance for a variety of applications. Its low dropout voltage, adjustable output, and low noise characteristics, combined with protection features and compact packaging, make it a versatile and efficient power management solution.
