LT3060ITS8#TRPBF - Low Dropout Linear Regulator

The LT3060ITS8#TRPBF is a high-performance, low dropout linear regulator (LDO) from Linear Technology, designed to provide precision voltage regulation with a minimal voltage drop. This regulator offers an optimal solution for applications that require a low noise, high voltage accuracy, and the ability to operate with a low input-to-output voltage differential.

Key Features:

• Adjustable Output: The output voltage is adjustable from 1.2V to 45V with a single external resistor, providing great flexibility for a variety of applications.
• Low Dropout Voltage: The LT3060 features a low dropout voltage of only 300mV at full load, ensuring efficient operation even when the input voltage is close to the output voltage.
• High Output Current: Capable of delivering up to 45mA of continuous output current, this LDO can power a range of devices.
• Low Noise: With a low output noise of only 30µVRMS, the LT3060 is ideal for noise-sensitive applications such as precision instrumentation and RF supply.
• Stable with Low ESR Ceramic Capacitors: The regulator is stable with ceramic output capacitors, which are smaller, more reliable, and have lower equivalent series resistance (ESR) than other types of capacitors.
• Thermal Protection: Built-in thermal shutdown and current limit protections safeguard the regulator and the application from overcurrent and overheating conditions.
• Wide Operating Temperature Range: The device is specified for operation from -40°C to 125°C, making it suitable for industrial and automotive environments.

Applications:

• Portable and battery-powered equipment
• Automotive power supplies
• Industrial supplies
• Medical devices
• Telecommunications infrastructure
• High-end audio

The LT3060ITS8#TRPBF from Linear Technology is a versatile and reliable choice for any design requiring a high-quality voltage regulator. Its small footprint, combined with its excellent performance characteristics, makes it an ideal choice for space-constrained applications that cannot compromise on power integrity.
