Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Linear Technology/Analog Devices
Status Obsolete
Type DC DC Regulator
Topology Step-Down (Buck)
Internal Switch(s) Yes
Voltage - Supply (Minimum) 4.5V
Voltage - Supply (Maximum) 55V
Voltage - Output 55V
Current - Output / Channel 80mA (Switch)
Frequency 850kHz
Dimming PWM
Applications Signage
Temperature Range - Operating -40°C ~ 85°C
Mounting Style SMD
Manufacturer Package 8-VFSOP (0.049", 1.25mm Width)
Supplier Device Package SC-70
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 739482-LT3590ESC8
Popularity Low
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LT3590ESC8 CAD Model

Description

Linear Technology's LT3590ESC8: A Robust LED Driver Solution

The LT3590ESC8 is a highly efficient, fixed frequency, step-up DC/DC converter specifically designed to drive LEDs. Manufactured by Linear Technology, now part of Analog Devices, this product stands out for its ability to provide a constant current to ensure uniform brightness in LED applications. It is a versatile solution suitable for a variety of industries, including automotive, industrial, and consumer electronics, where reliable and consistent LED performance is critical.

One of the key features of the LT3590ESC8 is its wide input voltage range, which spans from 3V to 30V, making it flexible for use in systems with varying power supplies. This feature is particularly beneficial for applications that may experience fluctuations in power supply or need to accommodate different power sources.

The device is capable of driving up to ten white LEDs in series from a 12V input, delivering up to 30mA of LED current. This series connection ensures that each LED receives the same current, resulting in uniform brightness across all LEDs. For applications requiring more brightness or higher currents, multiple LT3590ESC8s can be connected in parallel, thereby increasing the total available current to the LEDs.

Efficiency is a crucial aspect of any power management solution, and the LT3590ESC8 does not disappoint. It incorporates an internal 0.22Ω switch that allows for efficiencies up to 85%. Additionally, the device features a unique True Color PWM™ dimming capability, which provides a wide dimming ratio, making it ideal for applications where precise control over LED brightness is necessary.

The LT3590ESC8 comes in a compact, thermally efficient SC-70 package, which is highly beneficial for space-constrained applications. The small footprint of the package does not compromise its thermal performance, ensuring the device operates reliably over a wide temperature range.

Overall, the LT3590ESC8 from Linear Technology is a robust, efficient, and flexible solution for powering LEDs. Its ability to provide a constant current output, coupled with its high efficiency and dimming capabilities, makes it an excellent choice for designers looking to enhance their LED lighting systems.
