LTC3736EGN

Part No LTC3736EGN
Manufacturer Linear Technology
Description Dual 2-Phase, No RSENSE Synchronous Controller with Output Tracking
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

RoHS State Request Verification
Manufacturer Linear Technology
Win Source Part Number 1208877-LTC3736EGN
Manufacturer Homepage www.linear.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LTC3736EGN CAD Model

Description

Introducing the LTC3736EGN Dual PolyPhase® Synchronous Step-Down Controller

The LTC3736EGN is a cutting-edge power management solution from Linear Technology, designed for high-performance applications that require efficient voltage regulation and power distribution. This dual PolyPhase synchronous step-down controller is engineered to meet the rigorous demands of modern electronic devices, providing precise voltage control, high efficiency, and exceptional thermal performance.

Key Features and Benefits

  • Dual Output Capability: The LTC3736EGN is capable of controlling two outputs simultaneously, making it an ideal choice for systems that require multiple regulated voltages. Its dual-phase operation reduces input and output ripple, resulting in cleaner power delivery.
  • Phase-Lockable Fixed Frequency: Operating from 250kHz to 750kHz, the LTC3736EGN allows users to set a fixed frequency or synchronize it to an external clock, ensuring low noise and compatibility with sensitive RF and data communication systems.
  • High Efficiency: With its synchronous rectification and low dropout operation, this controller achieves high efficiency across a wide range of load currents, helping to extend battery life in portable applications.
  • Wide Input Voltage Range: The LTC3736EGN operates from an input voltage range of 2.75V to 9.8V, accommodating a variety of power sources, from single-cell lithium-ion batteries to intermediate bus voltages.
  • Robust Protection Features: The device includes overvoltage protection, overcurrent protection, and thermal shutdown, ensuring reliable operation and safeguarding against a range of potential fault conditions.
  • Compact Package: Housed in a 24-lead SSOP package, the LTC3736EGN is designed for space-constrained applications without compromising on performance.

Applications

The LTC3736EGN is versatile enough to be used in a wide array of applications. It is particularly well-suited for portable devices, including laptops and handheld instruments, as well as industrial and telecommunications equipment, where efficient power conversion is critical.

Conclusion

With its advanced features and robust design, the LTC3736EGN from Linear Technology stands out as a superior choice for designers looking to optimize their power management systems. Its dual-channel capability, high efficiency, and comprehensive protection make it a reliable and flexible solution for a multitude of power regulation needs.
