Products specifications

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Tube/Rail
Status Active
Type N+1 ORing Controller
Polarity N-Channel
Internal Switch(s) Yes
Delay Time - ON 200μs
Delay Time - OFF 300ns
Current - Output (Max) 5A
Operating Supply Current 600μA
Supply Voltage - Operating 9 V to 26.5 V
Applications N+1 Power Supplies, High Availability
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 16-TSSOP-EP
Win Source Part Number 137085-LTC4358CFE#PBF
Ultra Librarian 3D Model Ultra Librarian LTC4358CFE#PBF CAD Model

Description

Linear Technology LTC4358CFE#PBF - Ideal Diode Controller with Reverse Input Protection

The LTC4358CFE#PBF is a high-performance ideal diode controller from Linear Technology, designed to replace power Schottky diodes with N-channel MOSFETs for a more efficient, lower loss solution. This product is tailored for power supply designers who are looking to enhance the efficiency and thermal performance of their applications, such as automotive, industrial, and datacom systems.

The controller operates by monitoring the voltage drop across the external MOSFET and activates it when the forward voltage is detected, ensuring the MOSFET operates in a low loss, forward-biased condition. This method significantly reduces power dissipation and heat generation compared to a traditional Schottky diode, especially in applications with substantial current requirements.

One of the hallmark features of the LTC4358CFE#PBF is its reverse input protection capability. In the event of a reverse input, the controller promptly turns off the MOSFET to prevent any reverse current flow, thereby safeguarding downstream components from potential damage. This is particularly vital in systems where reverse polarity could be accidentally applied.

The LTC4358CFE#PBF comes in a compact 16-pin TSSOP package, which is ideal for space-constrained applications. It operates across a wide voltage range of 9V to 80V, providing versatility for various system voltages and ensuring compatibility with a broad array of applications. Additionally, the device has an operating temperature range of -40°C to 85°C, making it suitable for use in harsh environments.

With its fast turn-on and turn-off times, the LTC4358CFE#PBF minimizes power loss during transitions, and its low quiescent current helps maintain efficiency even in low-power or standby modes. This makes the device an excellent choice for systems that require efficient power management and high reliability.

In summary, the LTC4358CFE#PBF from Linear Technology is a robust, efficient, and reliable ideal diode controller that enhances system performance by replacing power Schottky diodes with N-channel MOSFETs. With its built-in reverse input protection and high-efficiency operation, it is an excellent choice for a wide range of power supply applications.
