LTC6101ACS5 High Voltage, High-Side Current Sense Amplifier

The LTC6101ACS5 from Linear Technology is a high-performance current sense amplifier that provides a precise, easy-to-use solution for measuring current in high-voltage systems. This robust device is capable of monitoring current via a sense resistor over a wide range of voltages, making it an ideal choice for a variety of applications including power management, battery monitoring, and overcurrent protection.

Key Features of the LTC6101ACS5:

• Wide Input Voltage Range: Designed to operate over a wide input voltage range, the LTC6101ACS5 is suitable for systems with supply voltages from 4V to 60V, ensuring versatility in different application environments.
• High-Side Current Sensing: The high-side current sensing capability allows for the measurement of the load current without interfering with the ground path of the load, providing a safer and more accurate reading.
• Low Offset Voltage: The device features a low input offset voltage, which enhances the accuracy of current measurement, especially in low-side applications where voltage drops are minimal.
• Quiescent Current: The LTC6101ACS5 boasts a low quiescent current, making it an energy-efficient choice for battery-powered and energy-conscious designs.

The LTC6101ACS5 is housed in a compact SOT-23 package, which is ideal for space-constrained applications. Its small footprint does not compromise its performance or reliability, making it a preferred choice for designers looking to save on board space without sacrificing quality.

Applications:

• Automotive Battery Monitoring
• Power Management Systems
• Portable Equipment
• Overcurrent and Fault Protection Circuits

With its combination of high voltage capability, precision, and small size, the LTC6101ACS5 from Linear Technology stands out as a top-tier solution for current sensing applications. Whether it's for industrial, automotive, or consumer electronics, this current sense amplifier is engineered to deliver reliable performance in demanding environments.
