The LTM9001IV-AA#PBF is a complete system in a package designed by Linear Technology, which now operates under Analog Devices, Inc. This innovative product is part of the LTM9001 series, known for its high-performance µModule (micromodule) ADCs (Analog-to-Digital Converters). The LTM9001IV-AA#PBF is an integrated solution aimed at streamlining the design process for data acquisition systems, particularly in demanding applications such as medical imaging, communications systems, and industrial process control.

Key Features

• Integrated ADC: The product features a 14-bit, 125Msps (mega samples per second) ADC, providing high-speed and high-resolution data conversion.
• Analog Input: It comes with an optimized front-end design, including a transformer-coupled input, which allows for easy interfacing with a wide range of signal sources.
• Signal Conditioning: The onboard signal conditioning circuitry includes a low-noise amplifier and an anti-aliasing filter, ensuring signal integrity and reducing design complexity.
• Power Efficiency: Designed with power efficiency in mind, it minimizes power consumption while maintaining performance, making it suitable for portable and energy-sensitive applications.
• Compact Design: The LTM9001IV-AA#PBF is encapsulated in a compact 11.25mm x 15mm x 2.82mm BGA (ball grid array) package, providing a space-saving solution for dense PCB layouts.

Applications

The LTM9001IV-AA#PBF is versatile and suitable for a broad range of applications, including:

• Medical Imaging Systems
• High-Speed Data Acquisition
• Communications Infrastructure
• Industrial Process Control
• Instrumentation

Quality and Reliability

Linear Technology's commitment to quality ensures that the LTM9001IV-AA#PBF meets stringent standards for performance and reliability. The product is designed for industrial temperature ranges, demonstrating its robustness in various environmental conditions. As a result, engineers and designers can confidently integrate this µModule ADC into their systems, knowing that it will deliver consistent performance and long-term reliability.
