Same model may have multiple batches, images only for reference.
0298225.ZXEH Real Image
Same model may have multiple batches, images only for reference.

0298225.ZXEH

Part No 0298225.ZXEH
Manufacturer Littelfuse Inc.
Catalog Fuses
Description FUSE AUTO 225A 32VDC AUTO LINK / 225 A AC 32 V DC Fuse Automotive Bolt Mount Auto Link
Datasheet
0298225.ZXEH Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection>Fuses
Mfr Littelfuse Inc.
Series MEGA®
Package Bulk
Mounting Type Bolt Mount
Fuse Type Automotive
Current Rating (Amps) 225 A
Voltage Rating - DC 32 V
Response Time Slow Blow
Package / Case Auto Link
Breaking Capacity @ Rated Voltage 2kA
Melting I2t 257000
Temperature Range - Operating -40°C ~ 125°C
Color Tan
Dimension 1.149" L x 0.750" W x 0.390" H (29.20mm x 19.05mm x 9.90mm)
DC Cold Resistance 0.000222 Ohms
MSL Level Not Applicable
ECCN EAR99
HTSUS 8536.10.0040
Other Names 0298225ZXEH,298225.,-0298225.ZXEH,0298225.ZXEH-ND,F4774,298225
Standard Package 500
Win Source Part Number 991780-0298225.ZXEH
Ultra Librarian 3D Model Ultra Librarian 0298225.ZXEH CAD Model

Description

The Littelfuse Inc. MEGA® 991780-0298225.ZXEH is an automotive type slow blow fuse.

  • Voltage Rating: 32V DC
  • Breaking Capacity @ Rated Voltage: 2kA
  • Melting I2t: 257000
  • DC Cold Resistance: 0.000222 Ohms
  • Packaging: Bulk
  • Mounting: Bolt mount
  • Package/Case: Auto link
  • Dimension: 1.149" L x 0.750" W x 0.390" H (29.20mm x 19.05mm x 9.90mm)
  • Current Rating: 225 A
  • Approval: ECCN: EAR99
  • MSL Level: Not applicable
