Same model may have multiple batches, images only for reference.
SM504R1K Real Image
Same model may have multiple batches, images only for reference.

SM504R1K

Part No SM504R1K
Manufacturer Littelfuse Inc.
Catalog Temperature Sensors - NTC Thermistors
Description THERM NTC 500KOHM 4140K MELF  /  NTC Thermistor 500k DO-213AC, MINI-MELF, SOD-80
Datasheet
SM504R1K Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers>Temperature Sensors - NTC Thermistors
Mfr Littelfuse Inc.
Series SM
Package Bulk
Product Status Obsolete
Resistance in Ohms @ 25°C 500k
Resistance Tolerance ±10%
B0/50 4140K
Temperature Range - Operating 220°C
Mounting SMD (SMT)
Package / Case DO-213AC, MINI-MELF, SOD-80
Standard Package 1
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8533.40.8070
Win Source Part Number 1233991-SM504R1K
Ultra Librarian 3D Model Ultra Librarian SM504R1K CAD Model

Description

The SM504R1K is a temperature sensor that is an excellent solution for your electronic needs.

  • Series: SM
  • Resistance in ohms @ 25°C: 500k
  • Resistance Tolerance: ±10%
  • B0/50: 4140K
  • Package / Case: DO-213AC, MINI-MELF, SOD-80
  • Temperature Range - Operating: 220°C
  • REACH: unaffected by REACH
  • HTSUS: 8533.40.8070
  • Manufacturer: Littelfuse Inc.
  • Status: obsolete
